A LOOK AT THE GLEANER S9 SERIES COMBINE
GLEANER S9 SERIES COMBINE
The Gleaner combine design is fundamentally different, offering a level of harvesting performance unmatched by other combines. The Gleaner S9 Series adds even more harvesting performance, new technologies, increased comfort, and ultimate convenience.
REQUEST PRICING TODAY!
GLEANER S9 SERIES SPECIFICATIONS
| Model | Max Boost HP | SAE Rated HP | Engine | Transmission | Grain Bin Capacity (bu.) | Unload Rate Bu./Sec | Base Machien Weight with Tires (lb) |
|---|---|---|---|---|---|---|---|
| S96 | 398 HP | 322 HP | AGCO POWER™ 8.4L Twin-Turbo, 6-Cylinder | 4-speed electronically shifted w/proportional hydrostatic | 390 (13,743) | 4.0 | 32,620 |
| S97 | 451 HP | 375 HP | AGCO POWER™ 9.8L Twin-Turbo, 7-Cylinder | 4-speed electronically shifted w/proportional hydrostatic | 390 (13,743) | 4.0 | 32,920 |
| S98 | 471 HP | 430 HP | AGCO POWER™ 9.8L Twin-Turbo, 7-Cylinder | 4-speed electronically shifted w/proportional hydrostatic | 390 (13,743) | 4.0 | 32,920 |
-
EFFICIENT FEEDING, THRESHING AND SEPARATION
Because of the way the Gleaner combine handles and processes material, the direction and flow of the crop mat never changes. This efficiency allows the processor to move a large volume of material while needing less horsepower.
-
A CLEAN GRAIN SAMPLE WITH MINIMAL LOSS
The cleaning shoe of the Gleaner is able to efficiently clean a large volume of material and produce a premium sample in the grain tank, regardless of the slope of the terrain.
-
INCREASED FUEL ECONOMY
The simple and easy to maintain drive systems move power through the machine without the inefficiencies of gearboxes or hydraulic motors. More power goes to the act of harvesting and less fuel is used to do it.
-
EASY TO MAINTAIN AND SERVICE
Complexity creates clutter. The reduced complexity of the Gleaner combine allows for easy access to maintain and service the machine.
-
FASTEST STANDARD AVERAGE UNLOADING RATE
The Direct Flow unloading auger is able to unload at a sustained 4 bushels per second and empty the 390 bushel grain tank in 98 seconds. The vertical and angled walls of the grain tank promote better cleanout of the grain tank when unloading.
