A LOOK AT THE FENDT MOMENTUM PLANTER
FENDT MOMENTUM PLANTERS
Maximize seed placement and productivity with Fendt planters from Butler Machinery—designed for today’s most demanding operations.
Fill out the form today for pricing or to order your planter for next spring!
DEVELOPED TO HELP YOU TAKE ON EVEN MORE
-
CONSISTENTLY ACCURATE PLANTING
Find consistent seed placement and planting depth with Momentum and its unparalleled 52" of vertical planting range. The Vertical Contouring Toolbar offers three independent toolbars following the topography of the terrain and flexing through the field to make sure your row unit technology can do its work and give you consistent emergence and a healthy crop.
-
LOAD LOGIC WEIGHT MANAGEMENT SYSTEM
The Fendt Momentum planter, equipped with Load Logic provides you with a solution to the compaction issues that are otherwise created in non-optimal conditions. Fendt Momentum's Load Logic system, automatically transfers weight off the row units of the planter by lifting and adjusting the planter frame to minimize row unit downforce.
The system has two automatic modes of operation, Load Balance, which distributes weight across the entire frame, or Controlled Traffic, which shifts compaction pressure to follow tractor path. -
TIRE INFLATION SYSTEM
The tire inflation system is part of the LoadLogic weight management system. Various sensors help automatically adjust the tire pressure.
-
IN-LINE CENTER TANDEM WHEELS ELIMINATE PINCH ROWS
Not only are these automatic weight distribution adjustments to the planter frame and tire pressures assisting in reducing compaction, but so too is the tire configuration. The planter features in-line center tandem wheels, which follow the affected row path already created by the tractor tires, thereby controlling traffic through the field and limiting compaction. This design, along with its front of frame mounted tire configuration, completely eliminates pinch rows, whereas conventional row unit planters have upwards of 6 compaction affected pinch rows.
-
INCREASED CAPACITY SEED TANKS
Higher capacity means fewer fills throughout the busy planting season, the Fendt Momentum features twin 65 bu. seed tanks for higher capacity and is easily accessed with a wide platform.
-
HIGH-CAPACITY LIQUID FERTILIZER
The Fendt Momentum planter offers an optional 1,000 gallon liquid fertilizer system, allowing you to cover more ground and make fewer stops. Single band Precision Planting Conceal options can be equipped directly from the factory.
-
VSET METERING UNIT
The vSet is easy to use, incredibly accurate and easy to maintain. It has an extremely high singulation accuracy.
-
IN FURROW FERTILIZER PLACEMENT
The Conceal fertilizer application system is equipped with a single-sided application knife. The applicaiton knife is located between the depth control wheel and double disc coulter. The application point is 3 inches beside the furrow at a depth of 0.75" to 1.5." As Conceal works directly next to the seed furrow, the application is perfectly placed next to the seed furrow, regardless of the terrain and cornering. A maximum of 71 GPM can be applied.
SPECIFICATIONS
| MODEL | HP REQUIRED at 5 MPH | HP REQUIRED at 10 MPH | BAR WIDTH | EST. WEIGHT (empty) | CFS CAPACITY | LIQUID CAPACITY |
|---|---|---|---|---|---|---|
| FTPM16-30 | 8-12 HP per row | 10-20 HP per row | 40' | 23,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM24-20 | 8-12 HP per row | 10-20 HP per row | 40' | 26,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM24-22 | 8-12 HP per row | 10-20 HP per row | 40' | 26,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM31-15 | 8-12 HP per row | 10-20 HP per row | 40' | 29,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM32-15 | 8-12 HP per row | 10-20 HP per row | 40' | 29,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM24-30 | 8-12 HP per row | 10-20 HP per row | 60' | 29,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM36-20 | 8-12 HP per row | 10-20 HP per row | 60' | 34,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM36-22 | 8-12 HP per row | 10-20 HP per row | 60' | 34,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM47-15 | 8-12 HP per row | 10-20 HP per row | 60' | 34,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
| FTPM48-15 | 8-12 HP per row | 10-20 HP per row | 60' | 38,000 lbs | (Twin)65bu/130bu | 1,000 gal. |
FENDT GOLD STAR CUSTOMER CARE WARRANTY
-
THE WARRANTY
Three years or 6,500 acres (40' models) or 10,000 acres (60' models) whichever occurs first.
-
THE MAINTENANCE
Annual inspections (one per year) during the term.
-
THE SAVINGS
Gold Star saves $8,000 per year in annual maintenance costs. Over the 3-year term, that is a $24,000 value.
-
THE RESIDUAL
Fendt Momentum planters enjoy some of the highest resale values in the industry. The Gold Star program ensures that all Fendt products are well-maintained, documented and ready for the next task with their next owner.
-
THE PARTS
To ensure your Fendt Momentum is maintained to the highest standards, only certified AGCO parts are used for repairs. Our system fill rates are some of the highest in the industry, to ensure we have the right parts for your machine when it's needed.
