Engine
|
Bore
|
5.1 in
|
|
Displacement
|
762.8 in³
|
|
Engine Model
|
Cat® C13
|
|
Engine Model - U.S. EPA Tier 4 Final/EU Stage IV
|
Cat® C13
|
|
Gross Power - SAE J1995
|
375 hp
|
|
Net Power - ISO 14396
|
370 hp
|
|
Net Power - SAE J1349
|
367 hp
|
|
No Engine De-rating Required Below
|
12500 ft
|
|
Peak Engine Torque Gross (SAE J1995)
|
1579 lb/ft
|
|
Peak Engine Torque Net (SAE J1349)
|
1554 ft·lbf
|
|
Peak Engine Torque Speed
|
1200 r/min
|
|
Stroke
|
6.2 in
|
Wheel Base Length
|
Long Wheel Base
|
215.2 in
|
|
Standard Wheel Base
|
156.7 in
|
Weights
|
Rated Payload
|
38.9 ton (US)
|
Transmission
|
Forward - 1
|
5 mile/h
|
|
Forward - 2
|
9 mile/h
|
|
Forward - 3
|
14 mile/h
|
|
Forward - 4
|
21 mile/h
|
|
Forward - 5
|
29 mile/h
|
|
Forward - 6
|
34 mile/h
|
|
Reverse - 1
|
6 mile/h
|
Service Refill Capacities
|
Cooling System
|
21.9 gal (US)
|
|
DEF Tank
|
5.3 gal (US)
|
|
Engine Crankcase
|
10 gal (US)
|
|
Final Drives/Differential
|
33 gal (US)
|
|
Fuel Tank
|
108.8 gal (US)
|
|
Hydraulic System
|
29.1 gal (US)
|
|
Output Transfer Gear Box
|
6.3 gal (US)
|
|
Transmission
|
12.4 gal (US)
|
Standards
|
Brakes
|
ISO 3450:2011
|
|
Cab - FOPS
|
ISO 3449:2005 Level II
|
|
Cab - ROPS
|
ISO 3471:2008
|
|
Steering
|
ISO 5010:2019
|
Steering
|
Lock to Lock
|
4.75 seconds @ 60 rpm
|
Turning Circle
|
Note
|
Dimensions are for machines equipped with 23.5 R25 tires.
|
|
Turning Dimensions - Aisle Width
|
210 in
|
|
Turning Dimensions - Clearance Radius
|
318 in
|
|
Turning Dimensions - Inside Radius
|
153 in
|
|
Turning Dimensions - SAE Turning Radius
|
294 in
|
|
Turning Dimensions - Steer Angle - Left/Right
|
45 °
|
