Get a quoteAP400
Smooth and Simple
More Comfort – More Performance – More Versatility
-
Compact Design
The small footprint simplifies maneuverability in tight spaces, while the lighter weight and optimal width accommodates easy transport.
-
Simple Operation
The single sliding console, easy-viewing display, and unobstructed visibility to the hopper combine to simplify operation.
-
More Flexibility
Configurable screed designs, high transport speeds, and serviceable components provide contractors with excellent flexibiity.
Dimensions
| Operating Length | 19 ft |
| Operating Width | 10.75 ft |
| Overall Height | 11 ft |
| Paving Range with SE47 FM | 2.4 m - 5.9 m (8' - 19' 6") |
| Paving Range with SE47 V | 2.4 m - 6.1 m (8' - 20') |
| Transport Height | 8.6 ft |
| Transport Length | 18.1 ft |
| Transport Width | 8.5 ft |
| Truck Entry Height | 21 in |
Engine
| Engine Model | Cat C3.6 |
| Gross Power | 120 hp |
Operating Specifications
| Maximum Paving Speed | 200 ft/min |
| Maximum Throughput Capacity | 853 ton(US)/h |
| Maximum Travel Speed | 10 mile/h |
Weights
| Operating weight with SE47 FM | 30000 lb |
| Operating weight with SE47 V | 29800 lb |
| Shipping Weight - Paver Only | 23327 lb |
Service Refill Capacities
| Cooling System - Total | 6.3 gal (US) |
| DEF Tank | 5 gal (US) |
| Fuel Tank | 53 gal (US) |
| Hydraulic Oil Tank | 32 gal (US) |
| Washdown Spray Tank | 8.5 gal (US) |
