854 Wheel Dozer

854 Wheel Dozer

The Perfect Match

Get a quote

More Comfort – More Performance – More Versatility

  • Versatile & Flexible

    Combines speed, mobility and versatility to support multiple activities in large-dozing applications

  • Quick Cycle Times

    Thanks to high speed in reverse

  • Comfortable & Productive Cab

    Unparalleled operator comfort and ergonomics help you get the most from your machine — shift after shift

Engine

Bore 5.7 in
Displacement 1958 in²
Emissions (Tier 2 Equivalent): Gross Power - SAE J1995 907 hp
Emissions (Tier 2 Equivalent): Net Power ISO - 9249 823 hp
Emissions (U.S. EPA Tier 4 Final): Gross Power - SAE J1995 900 hp
Emissions (U.S. EPA Tier 4 Final): Net Power ISO - 9249 814 hp
Engine Model Cat C32B
Gross Power 907 hp
Note (1) Net power advertised is the power available at the flywheel when the engine is equipped with fan, air cleaner, muffler and alternator.
Note (2) Net torque rise meets SAE J139.
Note (3) No engine derating required up to 3050 m (10,000 ft) altitude.
Peak Torque - 1,200 rpm 3139 lb/ft
Rated Speed 1750 r/min
Stroke 6.4 in
Torque Rise 30 %

Weights

Operating Weight 224647 lb

Transmission

Converter Drive - Forward 1 4.4 mile/h
Converter Drive - Forward 2 7.7 mile/h
Converter Drive - Forward 3 13.2 mile/h
Converter Drive - Reverse 1 4.8 mile/h
Converter Drive - Reverse 2 8.4 mile/h
Converter Drive - Reverse 3 14.6 mile/h
Direct Drive - Forward 1 Lock-up disabled
Direct Drive - Forward 2 8.1 mile/h
Direct Drive - Forward 3 14.2 mile/h
Direct Drive - Reverse 1 5 mile/h
Direct Drive - Reverse 2 8.9 mile/h
Direct Drive - Reverse 3 15.6 mile/h
Note Travel speeds based on 45/65-45 L-5 46 ply tires.
Transmission Type Cat Planetary Power Shift

Hydraulic System - Lift/Tilt

Cylinder, Double Acting - Tilt and Tip, Bore and Stroke 267 mm Ă— 286 mm (0.88 ft Ă— 0.94 ft)
Cylinders, Double Acting - Lift, Bore and Stroke 177 mm Ă— 1760 mm (0.58 ft Ă— 5.8 ft)
Output at 1,850 rpm and 6900 kPa (1,000 psi) 161 gal/min

Service Refill Capacities

Cooling System 53 gal (US)
Crankcase 32 gal (US)
Differential - Final Drives - Front 98 gal (US)
Differential - Final Drives - Rear 90 gal (US)
Fuel Tank - Standard 413 gal (US)
Hydraulic System - Steering and Engine Cooling Fan - Tank Only 77 gal (US)
Note (1) - All nonroad U.S. EPA Tier 4, European Union (EU) Stage IIIB and V, and Japan (MLIT) Step 4 diesel engines are required to use only Ultra Low Sulfer Diesel (ULSD) fuels containing 15 ppm (mg/kg) sulfer or less. Biodiesel blends up to B20 (20% blend by volume) are acceptable when blended with 15 ppm (mg/kg) sulfer or less ULSD. B20 should meet ASTM D7467 specification (biodiesel blend stock should meet Cat biodiesel spec, ASTM D6751 or EN 14214. Cat DEO-ULS or oils that meet the Cat ECF-3, API CJ-4, and ACEA E9 specification are required. For further fluid specifications and guidelines, visit: http://parts.cat.com/cda/files/3244668/7/SEBU6250-19.pdf
Transmission 45 gal (US)

Axles

Front Fixed
Rear Trunnion

Brakes

Brakes Meets ISO 3540:2011

Blades

Blade Capacities 30.5 to 44.8 m3 (40 to 58.6 yd3)

Dimensions (Approximate)

Centerline of Front Axle to Hitch 9.67 ft
Centerline of Rear Axle to Edge of Bumper 13.75 ft
Ground Clearance 27 in
Height - Top of Exhaust Pipe 17.17 ft
Height - Top of Hood 13 ft
Height - Top of ROPS 18.25 ft
Length - With Blade on Ground 44 ft
Wheel Base 19.25 ft

Hydraulic System - Steering

Minimum Turning Radius - Over Blade 31 ft
Relief Valve Setting 5004 psi
Steering System - Circuit Pilot, load sensing
Steering System - Pump Piston, variable displacement
Total Steering Angle 86 degrees

Operating Specifications

Operating Weight 224647 lb

Sound Performance Levels

Sound Performance • The machine sound power level was measured according to ISO 6395:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed. • The operator sound pressure level was measured according to ISO 6396:2008. The measurement was conducted at 70 percent of the maximum engine cooling fan speed. • Hearing protection may be needed when the machine is operated with a cab that is not properly maintained or when the doors or windows are open for extended periods or in a noisy environment.

Air Conditioning System

Air Conditioning The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). See the label or instruction manual for identification of the gas. If equipped with 1234yf (Global Warming Potential = 0.501), the system contains 2.1 kg of refrigerant, which has a CO2 equivalent of 0.001 metric tonnes (2.2 lbs). If equipped with 134a (Global Warming Potential = 1430), the system contains 1.8 kg (4.6 lb) of refrigerant, which has a CO2 equivalent of 3.003 metric tonnes (3.31 tons).

Cab

ROPS/FOPS ISO 3471:2008 and ISO 3449:2005 Level II Standards
