Engine - U.S. EPA Tier 4 Final/EU Stage V
|
Displacement
|
1959 in³
|
|
Engine Model
|
Cat® C32
|
|
Engine Power - Net SAE J1349/ISO 9249 - Forward
|
850 hp
|
|
Engine Power - Net SAE J1349/ISO 9249 - Reverse
|
955 hp
|
|
Note (1)
|
*Excludes all fan losses.
|
|
Note (2)
|
Engine ratings apply at 1,800 rpm.
|
|
Note (3)
|
Net power advertised is the power available at the flywheel when the engine is equipped with air cleaner, muffler, alternator, fan, and engine emissions controls as required.
|
Engine - U.S. EPA Tier 2 Equivalent
|
Displacement
|
1959 in³
|
|
Engine Model
|
Cat® C32
|
|
Engine Power - Net SAE J1349/ISO 9249 - Forward
|
850 hp
|
|
Engine Power - Net SAE J1349/ISO 9249 - Reverse
|
957 hp
|
|
Note (1)
|
*Excludes all fan losses.
|
|
Note (2)
|
Engine ratings apply at 1,800 rpm.
|
|
Note (3)
|
Net power advertised is the power available at the flywheel when the engine is equipped with air cleaner, muffler, alternator, fan, and engine emissions controls as required.
|
Fuel Tank Capacities
|
Fuel Tank - Total Volume
|
500 gal (US)
|
|
Fuel Tank - Usable Volume
|
475 gal (US)
|
Service Refill Capacities
|
Cooling System
|
46.8 gal (US)
|
|
Cooling System Refill - Tier 2 Equivalent Engine
|
41.7 gal (US)
|
|
Engine Crankcase
|
35.1 gal (US)
|
|
Final Drive - Each
|
12.4 gal (US)
|
|
Hydraulic System Chassis + Blade and Ripper (Carrydozer)
|
143.4 gal (US)
|
|
Hydraulic System Chassis + Blade and Ripper (Standard)
|
117.6 gal (US)
|
|
Hydraulic System Tank and Chassis
|
64.7 gal (US)
|
|
Hydraulic Tank
|
42.2 gal (US)
|
|
Power Train
|
120 gal (US)
|
|
Power Train - Refill Volume
|
103.3 gal (US)
|
|
Roller Frames - Each
|
24.8 gal (US)
|
Weights
|
Note (1)
|
D11 Operating Weight: Includes blade tilt cylinders, coolant, lubricants, full fuel tank, ROPS, FOPS cab, 11U ABR bulldozer, single-shank ripper with pin-puller, fast fuel, 710 mm (28 in) ES shoes, and operator.
|
|
Note (2)
|
D11 CD Operating Weight: Includes lubricant, coolant, full fuel tank, 915 mm (36 in) extreme service shoes, 11 Carrydozer, singleshank ripper, and operator.
|
|
Operating Weight
|
229800 lb
|
|
Operating Weight - Carrydozer
|
250665 lb
|
Hydraulic Controls
|
Combined Pump Output - Implement
|
177 gal/min
|
|
Pump Type
|
Variable displacement piston pump
|
Undercarriage
|
Ground Clearance*
|
30.6 in
|
|
Ground Contact Area
|
9781 in²
|
|
Ground Contact Area - CD
|
12605 in²
|
|
Grouser Height
|
4 in
|
|
Length - Track on Ground
|
175 in
|
|
Number of Carrier Rollers
|
1 per side (optional)
|
|
Pitch
|
12.5 in
|
|
Shoe Type
|
Extreme Service
|
|
Shoes/Side
|
41
|
|
Track Gauge
|
114 in
|
|
Track Rollers/Side
|
8
|
|
Width - Shoe
|
28 in
|
|
Width - Shoe - CD
|
36 in
|
Air Conditioning System
|
Note (1)
|
The air conditioning system on this machine contains the flourinated greenhouse gas refrigerant R134a (Global Warning Potential = 1430). The system contains 2.1 kg (4.6 lb) of refrigerant which has a CO2 equivalent of 3.003 metric tonnes (3.31 tons)
|
Standards
|
FOPS
|
Falling Objects Protective Structure (FOPS) meets the following criteria: ISO 3449:2005 LEVEL II
|
|
ROPS
|
Rollover Protective Structure (ROPS) meets the following criteria: ISO 3471:2008
|
|
Sound (1)
|
The exterior sound pressure level for the standard machine (ISO 6396:2008) is 116 dB(A) (sound suppressed).
|
|
Sound (2)
|
The operator equivalent sound pressure level (ISO 6396:2008) is 78 dB(A) (sound suppressed).
|
Transmission
|
1.0 Forward
|
2.5 mile/h
|
|
1.0 Reverse
|
3 mile/h
|
|
2.0 Forward
|
4.4 mile/h
|
|
2.0 Reverse
|
5.3 mile/h
|
|
3.0 Forward
|
7.6 mile/h
|
|
3.0 Reverse
|
9.1 mile/h
|
|
Drawbar Pull - 1 Forward
|
148200 ft·lbf
|
|
Drawbar Pull - 2 Forward
|
82300 ft·lbf
|
|
Drawbar Pull - 3 Forward
|
46250 ft·lbf
|
Blades
|
Carry Dozer - Blade capacity (SAE J1265)
|
57 yd³
|
|
Carry Dozer - Width with blade (over end bits)
|
263.9 in
|
|
Reclamation Universal - Blade capacity (SAE J1265)
|
55 yd³
|
|
Reclamation Universal - Width with blade (over end bits)
|
251.8 in
|
|
Semi-Universal (SU)* Capacity
|
35.6 yd³
|
|
Semi-Universal (SU)* Width Over Endbits
|
219.8 in
|
|
U-Blade Capacity
|
45 yd³
|
|
U-Blade Width
|
249.6 in
|
Ripper - Single Shank
|
Maximum penetration depth (standard tip)
|
63.5 in
|
|
Maximum penetration force * (shank vertical)
|
66000 lb
|
|
Pryout Force
|
148510 lb
|
Ripper - Single Shank, Deep Ripping
|
Maximum penetration depth (standard tip)
|
85.5 in
|
|
Maximum penetration force * (shank vertical)
|
66110 lb
|
|
Pryout Force
|
148510 lb
|
Ripper - Multi-Shank, Adjustable Parallelogram
|
Maximum Penetration - Standard Tip
|
43.3 in
|
|
Maximum Penetration Force - Shank Vertical
|
77350 lb
|
|
Overall Beam Width
|
131.1 in
|
|
Pry-Out Force - Multi-Shank Ripper with One Tooth
|
145640 lb
|
Dimensions - D11
|
Ground Clearance*
|
31.4 in
|
|
Height (ROPS/canopy)*
|
185.9 in
|
|
Length of Track on Ground
|
175 in
|
|
Length with SU-Blade** - No rear attachment
|
337.8 in
|
|
Note
|
*Includes grouser height for total dimensions on hard surfaces.
|
|
Overall Length SU-Blade and SS Ripper**
|
414.4 in
|
|
Track Gauge
|
114 in
|
|
Width at Outside of Track (710 mm Track Shoe)
|
142 in
|
Dimensions - D11 Carrydozer
|
Length with SU-Blade** - No rear attachment
|
345.1 in
|
|
Overall Length SU-Blade and SS Ripper**
|
421.7 in
|
|
Width at Outside of Track (710 mm Track Shoe)
|
149.8 in
|
