Operating Specifications - 300.9D VPS
|
Bucket Force
|
2000 lbf
|
|
Dumping Height - Maximum
|
80 in
|
|
Reach at Ground Level
|
119 in
|
|
Stick Force
|
1012 lbf
|
Engine
|
Emissions
|
Meets U.S. EPA Tier 4 Final/EU Stage V emission standards.
|
|
Engine Model
|
Yanmar 3TNV70
|
|
Net Power
|
13 hp
|
Engine - 300.9D VPS
|
Engine Type
|
Liquid Cooled, 3 Cylinder, Diesel
|
|
Fuel Tank Capacity
|
2.6 gal (US)
|
|
Gross Power
|
13 hp
|
Dimensions - 300.9D VPS
|
Length × Width × Height
|
2476 × 700 × 1507 mm (108 × 28 × 59 in)
|
|
Operating Weight
|
2399 lb
|
|
Shipping Weight
|
2178 lb
|
Hydraulic System - 300.9D VPS
|
Hydraulic Tank Capacity
|
3.7 gal (US)
|
|
Operating Pressure - Front Linkage and Travel
|
2466 psi
|
|
Operating Pressure - Swing Gear
|
1015 psi
|
|
Pump Flow
|
6 gal/min
|
|
Pump Type
|
Gear
|
|
Rotation Speed
|
8 r/min
|
Dimensions - HPU300
|
Length × Width × Height
|
930 × 720 × 1000 mm (36.5 × 28.3 × 39.5 in)
|
|
Operating Weight
|
423 lb
|
Blade - 300.9D VPS
|
Dig Depth
|
7 in
|
|
Height
|
8 in
|
|
Lift Height
|
8 in
|
|
Width
|
28 in
|
Hydraulics - HPU300
|
Connecting Hose Length
|
32.8 ft
|
|
Flow Rate
|
5.3 gal/min
|
|
Hydraulic Oil Tank Capacity
|
2.4 gal (US)
|
|
Operating Pressure
|
2756 psi
|
Motor - HPU300
|
Input Current
|
16A
|
|
Motor Type
|
3 Phase Electric Motor
|
|
Performance - Europe
|
10 hp
|
|
Performance - North America
|
12 hp
|
Travel System - 300.9D VPS
|
Track Width
|
7.1 in
|
|
Travel Speed
|
1.1 mile/h
|
