Engine
|
Bore
|
3 in
|
|
Displacement
|
69 in³
|
|
Emissions
|
Meets U.S. EPA Tier 4 Final and EU Stage V emission standards.
|
|
Engine Model
|
C1.1
|
|
Gross Power - SAE J1995:2014
|
21.6 hp
|
|
Net Power
|
21 hp
|
|
Net Power - 2,400 rpm - ISO 9249, 80/1269/EEC
|
21 hp
|
|
Note
|
Net power is tested per ISO 9249:2007 and 80/1269/EEC.
|
|
Note (1)
|
Engine power is tested per ISO 14396:2002.
|
|
Note (2)
|
Net power advertised is the power available at the flywheel when the engine is at rated speed and rated power when the engine is installed with the factory configured fan, air intake system, exhaust system, and alternator with a minimum alternator load.
|
|
Stroke
|
3.2 in
|
Weights
|
EU: CE Plate Weight with Cab***
|
4718 lb
|
|
EU: CE Plate Weight with Canopy***
|
4508 lb
|
|
Maximum Operating Weight with Cab**
|
4987 lb
|
|
Maximum Operating Weight with Canopy**
|
4588 lb
|
|
Minimum Operating Weight with Cab*
|
4535 lb
|
|
Minimum Operating Weight with Canopy*
|
4229 lb
|
|
Note (1)
|
*Minimum Weight is based on rubber tracks, operator, fixed undercarriage and full fuel tank.
|
|
Note (2)
|
**Maximum Weight is based on steel tracks, operator, expandable undercarriage and full fuel tank.
|
|
Note (3)
|
***CE Plate Weight is based on the most common EU configuration. Includes 75 kg (165 lb) operator and full fuel tank and excludes bucket.
|
|
Operating Weight
|
4987 lb
|
Dimensions - Long Stick
|
Boom Height - Shipping Position
|
40.2 in
|
|
Boom In Reach
|
65.4 in
|
|
Boom Swing - Left
|
65 °
|
|
Boom Swing - Right
|
50 °
|
|
Dig Depth
|
101.2 in
|
|
Maximum Blade Depth
|
11.6 in
|
|
Maximum Blade Height
|
11.2 in
|
|
Maximum Dig Height
|
142.5 in
|
|
Maximum Dump Clearance
|
103.9 in
|
|
Maximum Reach
|
168.1 in
|
|
Maximum Reach - Ground Level
|
165.7 in
|
|
Minimum Ground Clearance Below Undercarriage
|
5.9 in
|
|
Note
|
*Overall Shipping Length depends on blade position during shipment.
|
|
O/A Shipping Height
|
90.6 in
|
|
O/A Undercarriage Length
|
72.8 in
|
|
Overall Shipping Length*
|
152.8 in
|
|
Stick Length
|
45.7 in
|
|
Swing Bearing - Height
|
17.4 in
|
|
Tail Swing
|
29.5 in
|
|
Track Belt/Shoe Width
|
9.8 in
|
|
Track Width - Expanded
|
55.12 in
|
|
Track Width - Retracted
|
42.9 in
|
|
Vertical Wall
|
76.4 in
|
Blade
|
Height
|
8.9 in
|
|
Note
|
*Expanded – 1400 mm (55 in)
|
|
Width*
|
42.9 in
|
Dimensions - Standard Stick
|
Boom Height - Shipping Position
|
42.1 in
|
|
Boom In Reach
|
65.4 in
|
|
Boom Swing - Left
|
65 °
|
|
Boom Swing - Right
|
50 °
|
|
Dig Depth
|
93.3 in
|
|
Maximum Blade Depth
|
11.6 in
|
|
Maximum Blade Height
|
11.2 in
|
|
Maximum Dig Height
|
139.8 in
|
|
Maximum Dump Clearance
|
100.8 in
|
|
Maximum Reach
|
161.8 in
|
|
Maximum Reach - Ground Level
|
159.1 in
|
|
Minimum Ground Clearance Below Undercarriage
|
5.9 in
|
|
Note
|
*Overall Shipping Length depends on blade position during shipment.
|
|
O/A Shipping Height
|
90.6 in
|
|
O/A Undercarriage Length
|
72.8 in
|
|
Overall Shipping Length*
|
153.5 in
|
|
Stick Length
|
37.8 in
|
|
Swing Bearing - Height
|
17.4 in
|
|
Tail Swing
|
29.5 in
|
|
Track Belt/Shoe Width
|
9.8 in
|
|
Track Width - Expanded
|
55.12 in
|
|
Track Width - Retracted
|
42.9 in
|
|
Vertical Wall
|
72.8 in
|
Weight Increase from Minimum Configuration
|
Expandable Undercarriage
|
212 lb
|
|
Long Stick
|
18 lb
|
|
Steel Tracks
|
132 lb
|
Certification - Cab and Canopy
|
Roll Over Protective Structure (ROPS)
|
ISO 12117-2:2008
|
|
Tip Over Protective Structure (TOPS)
|
ISO 12117:1997
|
|
Top Guard
|
ISO 10262:1998 (Level I)
|
Hydraulic System
|
Auxiliary Circuit - Primary - Flow
|
8.7 gal/min
|
|
Auxiliary Circuit - Primary - Pressure
|
3553.4 psi
|
|
Auxiliary Circuit - Secondary - Flow
|
3.7 gal/min
|
|
Auxiliary Circuit - Secondary - Pressure
|
3553.4 psi
|
|
Digging Force - Bucket
|
4406.3 lbf
|
|
Digging Force - Stick - Long
|
2203.1 lbf
|
|
Digging Force - Stick - Standard
|
2540.3 lbf
|
|
Operating Pressure - Equipment
|
3553.4 psi
|
|
Operating Pressure - Swing
|
2132.1 psi
|
|
Operating Pressure - Travel
|
3553.4 psi
|
|
Pump Flow at 2,400 rpm
|
17.4 gal/min
|
|
Type
|
Load Sensing Hydraulics with Variable Displacement Piston Pump
|
Swing System
|
Machine Swing Speed
|
9.8 r/min
|
Sound
|
Average Exterior Sound Pressure (ISO 6395:2008)
|
93 dB(A)
|
|
Note
|
European Union Directive “2000/14/EC”
|
|
Operator Sound Pressure (ISO 6396:2008)
|
73 dB(A)
|
Service Refill Capacities
|
Cooling System
|
1 gal (US)
|
|
Engine Oil
|
1.2 gal (US)
|
|
Fuel Tank
|
6.9 gal (US)
|
|
Hydraulic System
|
6.9 gal (US)
|
|
Hydraulic Tank
|
4.8 gal (US)
|
Travel System
|
Gradeability - Maximum
|
30 degrees
|
|
Ground Pressure - Maximum Weight
|
3.9 psi
|
|
Ground Pressure - Minimum Weight
|
3.4 psi
|
|
Maximum Traction Force - High Speed
|
2967.5 lbf
|
|
Maximum Traction Force - Low Speed
|
4496.2 lbf
|
|
Travel Speed - High
|
2.7 mile/h
|
|
Travel Speed - Low
|
1.8 mile/h
|
